   Flex PCB Circuit Automatic depaneling is an automated depaneling device developed and patented by Suzhou Yu Shun Li Electronics Co., Ltd. based on the needs of the T8LEDFlex light belt on the market today. It is targeted at the Flex PCB Circuit of the Flex PCB Circuit circuit board Depressed, according to the width of the customer requirements of the width of the board width of the full-page cutting, the cutting effect is good, fast, much customer-friendly; for different sizes and specifications of the LEDFlex PCB Circuit products; to solve the customer manual depaneling slow, cutting poor results problem;

Features：

1, for Flex light belt, Flex PCB circuit, Flex light bar circuit board LEDFlex light belt, Flex PCB Circuit, Flex light bar for cutting;

2, manually adjust the cutting blade module level, to solve the Flex PCB circuit thickness of the problem;

3, v cut with V groove guide to ensure product quality;

4, high efficiency: Vmax = 400mm / s, and the speed adjustable;

5, high precision, easy maintenance, high security;

6, the machine is simple, easy to use, solid and durable;

7, cutting mode lifting range: 25mm;

8, for different width of the Flex PCB Circuit, only need to replace the knife and fixture can be, easy to adjust;

9, cutting mode using left and right recycling, improve cutting efficiency;

Main configuration：

Configuration name	unit	Quantity	Remarks
Drive motor	set	2	Reese step
Screw guide	set	3	Taiwan HIWIN
Pilot cylinder	set	5	Star Pneumatic
man - machine interface	set	1	Taiwan Weilun
Industrial control system	station	1	Industrial PLC
cutting Knife mold	set	1	Imported tungsten steel mold
Control software	set	1	Pinyao-auto
Timing belt	set	1	Import mute timing belt
The electromagnetic valve	set	3	Yade off
Switching power supply	set	1	Taiwan Mingwei
air filter	One	1	Brave Pneumatic

2. technical parameters

Equipment model	YSVC-1200	YSVC-1500
length	1200mm	1500mm
speed	500mm/sec
Repeat accuracy	±0.02mm
Resolution	0.01mm
operating system	PLC + man - machine interface
transfer method	Precision stepper motor + synchronous technology
Cutting mode	High precision rotating tungsten steel
Targeting	Positioning fixture + cylinder in place
Working power supply	AC220V  50-60HZ   1.0KW
Machine size	1350╳950╳1120mm	1650╳950╳1120mm
equipment weight	350KG	450KG
